The air blast sprayer is an intelligent plant protection device specifically designed for complex terrains such as mountains, hills, and orchards. Powered by a diesel engine and featuring a tracked walking structure, it boasts strong terrain adaptability, easily handling muddy, sloping, and other challenging conditions. With a large-capacity tank and a high-efficiency air-assisted spraying system, it achieves a spray diameter of 8-12 meters and uniform atomization. It supports independent nozzle control, flexibly adapting to the plant protection needs of different crops, significantly improving application efficiency and pesticide utilization. It is an ideal device for pest and disease control in orchards and forestry.
Parameters of the Air Blast Sprayer for Sale
| Item | Specification |
| Model | FL-16HP |
| Starting Method | Electric Start + Recoil Start |
| Spray Diameter | 8–12 m |
| Battery Model | 12V 20A |
| Tank Capacity | 200L |
| Motor Power | 600W × 2 (Brushless) |
| Spray Flow Rate | 17–26 L/min |
| Generator Power | 1500W |
| Nozzle Quantity | 10 (Individually Controllable) |
| Spray Pressure | 1–3.5 MPa |
Features of the Air Blast Sprayer
- Tracked Design: Utilizing a rubber track walking structure, the airblast orchard sprayer features low ground pressure and strong traction, enabling stable operation on complex terrains such as mud, slopes, and orchard rows. It is less prone to slipping and getting stuck.
- Dual Start Configuration: With a 16-horsepower diesel engine, the blast sprayer offers strong power and good fuel economy. It features both electric and manual start options, allowing for quick restart even with a depleted battery, suitable for field operations without a stable power supply.
- Air-Delivered Spraying: With a large-diameter air duct and 10 independently controllable nozzles, the air-delivered system precisely delivers atomized pesticides into the crop canopy. This reduces pesticide drift and improves pest and disease control effectiveness.
- Wide Pressure Adjustment: The spray pressure is adjustable between 1-3.5MPa, combined with a flow rate range of 17-26L/min, adapting to the application needs of different crops and pests.
- Large-capacity Medicine Tank: The air blast sprayer has a 200-liter large-capacity medicine tank. It can reduce the frequency of adding medicine during the operation and improve the efficiency of continuous operation.
Advantages of the Air Blast Sprayer
- High Efficiency: The combination of a tracked chassis and powerful engine makes the air blast sprayer far more efficient in mountainous orchards and hilly slopes than traditional wheeled sprayers. It provides a wide coverage area per application.
- High Pesticide Utilization: The combination of air-assisted spraying and independently controllable nozzles ensures that the pesticide adheres evenly to both sides of crop leaves, reducing waste and improving the comprehensiveness of pest and disease control.
- Strong Stability: The diesel engine provides ample power reserves, the brushless motor has a low failure rate, and the dual-start design avoids start-up failures in field operations. The overall equipment can operate stably for extended periods.
- Wide Compatibility: The spray diameter, pressure, and flow rate are all adjustable, and the nozzles can be individually switched on and off. It is suitable for both the conventional application of low-growing crops and the three-dimensional spraying needs of tall fruit trees.
- Reduced Labor Intensity: The remote control pesticide sprayer requires no manual carrying or towing. Operators can control it remotely, significantly reducing the labor intensity of manual pesticide application and minimizing the risk of direct contact with pesticides.
FAQ
It is specifically designed for complex terrains such as orchards, mountains, hills, and muddy fields. It can easily handle slopes and slippery surfaces, and unlike wheeled equipment, it doesn’t slip.
Yes. The air blast sprayer for sale has 10 independently controllable nozzles, which can turn on or off as needed. It flexibly adapts to the application height and range requirements of different crops.
Adjustable. The spray pressure of the air blast sprayer is adjustable from 1-3.5 MPa, and the flow rate from 17-26 L/min. Low pressure and low flow rate are suitable for seedlings, while high pressure and high flow rate are suitable for tall fruit trees.
The diesel engine operates within a reasonable noise level, and the airflow noise from the pneumatic conveying system is relatively gentle, which will not cause excessive interference to orchard crops and the surrounding environment.
Why Choose Foodline Machinery?
As a professional manufacturer of agricultural and forestry plant protection equipment, we have independent production workshops and a complete supply chain system. Our core power components and control systems all use high-quality industry-leading configurations and undergo multiple rounds of performance and stability testing before leaving the factory, ensuring that every piece of equipment can adapt to complex working conditions. Our products sold well in bulk to overseas markets, where we have built a strong reputation for efficient and durable plant protection equipment, providing cost-effective operational solutions to users worldwide.
